OS MIO+ 4K S2X + S2/T2/C Grey
Product Code:
01-08-0026
  • Manufacturer:
    EDISION
  • Barcode:
    5200378400685
  • Pieces per package:
    10
  • Pieces per pallet:
    300
  • Net weight:
    0.85 kg
  • Gross weight:
    1.07 kg
  • Dimensions per package:
    43x33x27
  • Uploaded on:
    26-08-2019
  • The product was removed:
    20-09-2023

EDISION OS MIO+ 4K S2X + S2/T2/C Grey with OLED display, is the new E2 LINUX 4Κ UHD, DVB-S2X + S2/T2/C combo receiver in the E2 LINUX range of EDISION receivers. It features 4K UHD resolution and has Multi Stream T2MI Tuner & Blindscan. It is equipped with a variety of the most advanced features in order to provide you with an exciting use of all its top characteristics, all in a compact and slim design! It is available in an elegant aluminum box, in 2 color choices, with features that include: E2 Linux operational system, DVB-S2X and DVB-T2/C Τuners, 4K UHD resolution, Multi Stream T2MI Tuner, Blindscan, Web browser and HbbTV support, Dual Core ARM at 1.5 GHz processor, 8GB eMMC/RAM 2GB DDR4 2400Mhz flash memory, OLED display, WiFi with two (2) external, detachable wifi antennas (included), Bluetooth on Board, 4K UHD Multimedia Player plus the exceptional and ergonomical IR remote control UNIVERSAL 2-in-1! All these combined with the overall EDISION quality and professional support, make it a superior option for you to enjoy!

Technical features:
- Type: 4K UHD E2 Linux Combo Reivever DVB-S2X + DVB-S/T2/C with Multi Stream Support
- 1 x Tuner DVB-S2X
- 1 x Tuner DVB-S2/T2/C
- Decoding: H.265/HEVC 10bit decoding support (covered by patents listed at patentlist.hevcadvance.com)
- Multi Stream T2MI & Blind Scan support
- Linux operational system
- Processor: Dual Core ARM 1.5 GHz
- FLASH 8GB eMMC/RAM 2GB DDR4 2400Mhz
- OLED Display
- 4K UHD Multimedia Player
- Web Browser & HbbTV support
- Free Internet Streaming TV and Radio
- Dual Band 2x2 Wi-Fi 802.11ac 5G/2.4G with MU-MIMO
- 2 x Pluggable Wi-Fi Antennas
- Bluetooth: embedded 2.1/3.0/4.0
- Unlimited channel memory
- Hyper-sensitive tyner for receiving even the weak-signal channels
- 1 x Smartcard reader
- 10/100 Mbps Ethernet interface
- 2 x USB2.0 ports
- 1 x HDMI 2.0a Connection
- 1 x jack to RS232
- 1 x jack to IR
- 1 x S/PDIF
- Channel switch in less than 1 second.
- Extensive ΕPG and programmed viewing via EPG
- Expandable Add-Ons & Plug-Ins
- Supports Bouquet list
- Multilingual OSD, Skin - support
- Channel search: Fully automatic/Manual
- Time Shift function and Multi Timers
- Supports Teletext & and OSD and VBI subtitles
- Compatible with DiSEqC 1.0, 1,1 ,1.2 and 1.3 (USALS)
- Supports SCR / CSS (EN50494 & EN50607)
- Power consumption less than 0.5 Watt, in low-power stand-by mode

Front Panel:
- Display: OLED
- Display Buttons: Power, Channel -/+

Back Panel:
- Input Sat-IF: 1x F-type
- Input RF: 1x IEC-type
- Connection TV: 1x HDMI
- Video output: 1x HDMI
- Audio output: Standard optical (S/PDIF)
- 2 x WiFi Antennas
- 1 x Smartcard slot
- 1 x Ethernet plug
- 1 x jack to RS232
- 1 x jack to IR
- 1 x DC in (for the external PSU)

Package contains:
- Universal Remote Control 2in1
- External PSU 12v
- Jack to IR cable
- USB extension cable
- 2 x Wi-Fi Antennas
- 2 x "ΑΑΑ" batteries
- Start Guide EN/DE/GR

General:
- Power Supply: 100 - 240 AC 50/60Hz
- Input Voltage: DC 12V 2.0A
- Power Consumption: max. 20.0W
- Power Consumption in standby: <0.5W
- Operating Temperature: 0°C ... +50°C
- Storage Temperature: -20°C ... +70°C
- Humidity Range: 10% ... 85% RH, non-condensing
- Case: Aluminum
- Dimensions: (W x H x D): 180x40x140 (mm)
- Weight: 0,7 kg
- Color: Grey
- Warranty: 2 years
