650102 4GNOVA 4G/LTE ANTENNA is a passive transmission and reception antenna for 4G extended coverage, enhancing the operator's network connection quality. Mobile 4G devices are more efficient in terms of power and consumption, saving battery and preventing the user from an exposure to excessive radiation. Optimized response on both the Uplink and the Downlink. This telephone antenna is based on a printed circuit board to avoid future alterations and to ensure mechanical quality. Passive antenna, no power consumption.
Technical features:
- Connectors: SMA Male (includes 7.5m cable)
- Polarization: Horizontal / Vertical
- Frequency band Mhz: 698...960 and 1700...2700
- Gain dBi: 7,5 and 7
- F/B ratio dB: >18 and >20
- Impedance Ohm: 50
- Windload N: 69,6 (@130 Km/h), 95,7(@150 Km/h)
- Protection index IP: 53
- Mast diameter mm: 20...50
